Chart Title ToolTip
ChartTitleToolTip.aspx
<%@ Page Language="C#" AutoEventWireup="true" %>
<%@Import Namespace="System.Web.UI.DataVisualization.Charting" %>
<!DOCTYPE html>
<script runat="server">
protected void Button1_Click(object sender, System.EventArgs e)
{
Chart1.Titles[0].ToolTip = "Sample ToolTip for Chart Title";
}
</script>
<html xmlns="http://www.w3.org/1999/xhtml">
<head id="Head1" runat="server">
<title>How to set change Chart Title ToolTip programmatically in asp.net</title>
<style type="text/css">
h2
{
color:DarkBlue;
font-style:italic;
}
</style>
</head>
<body>
<form id="form1" runat="server">
<div>
<h2>Chart example and tutorial: How to set change<br /> Chart Title ToolTip programmatically in asp.net</h2>
<hr width="625" align="left" color="LightBlue" />
<br />
<asp:Chart
ID="Chart1"
runat="server"
Width="625"
BackColor="DarkOliveGreen"
BorderlineColor="Olive"
BorderlineDashStyle="Solid"
BorderlineWidth="2"
>
<Titles>
<asp:Title
Text="Adobe Creative Suite 5"
ForeColor="Green"
Docking="Top"
BackColor="YellowGreen"
Font="Comic Sans MS, 12pt, style=Bold"
BorderColor="DarkGreen"
>
</asp:Title>
</Titles>
<Series>
<asp:Series
Name="AdobeCreativeSuite5"
YValueType="Int32"
ChartArea="DefaultChartArea"
ChartType="Bar"
Palette="Chocolate"
>
<Points>
<asp:DataPoint AxisLabel="Design Premium" YValues="1899" />
<asp:DataPoint AxisLabel="Design Standard" YValues="1299" />
<asp:DataPoint AxisLabel="Web Premium" YValues="1799" />
<asp:DataPoint AxisLabel="Production Premium" YValues="1699" />
<asp:DataPoint AxisLabel="Master Collection" YValues="2599" />
</Points>
</asp:Series>
</Series>
<ChartAreas>
<asp:ChartArea
Name="DefaultChartArea"
BorderDashStyle="Dot"
BorderWidth="2"
BorderColor="Green"
BackColor="OliveDrab"
>
<Area3DStyle Enable3D="true" LightStyle="Realistic" />
<AxisX>
<MajorGrid
Enabled="false"
/>
<LabelStyle ForeColor="Snow" />
<MajorTickMark Size="5" LineWidth="2" LineColor="YellowGreen" LineDashStyle="DashDot" />
</AxisX>
<AxisY>
<MajorGrid
Enabled="true"
LineColor="YellowGreen"
/>
<LabelStyle ForeColor="Snow" />
<MajorTickMark Size="5" LineWidth="2" LineColor="YellowGreen" LineDashStyle="DashDot" />
</AxisY>
</asp:ChartArea>
</ChartAreas>
</asp:Chart>
<br />
<asp:Button
ID="Button1"
runat="server"
Text="Set Chart Title ToolTip"
Font-Bold="true"
OnClick="Button1_Click"
ForeColor="DarkBlue"
Height="45"
/>
</div>
</form>
</body>
</html>
