Chart PaletteCustomColors
UsingChartPaletteCustomColors.aspx
<%@ Page Language="C#" AutoEventWireup="true" %>
<%@ Import Namespace="System.Drawing" %>
<!DOCTYPE html>
<script runat="server">
protected void Button1_Click(object sender, System.EventArgs e)
{
Chart1.Palette = ChartColorPalette.None;
Chart1.PaletteCustomColors = new Color[] { Color.Orange, Color.DarkOrange, Color.OrangeRed, Color.Salmon, Color.DarkSalmon };
}
</script>
<html xmlns="http://www.w3.org/1999/xhtml">
<head id="Head1" runat="server">
<title>How to use Chart PaletteCustomColors in asp.net</title>
<style type="text/css">
h2
{
color:DarkBlue;
font-style:italic;
}
</style>
</head>
<body>
<form id="form1" runat="server">
<div>
<h2>Chart example and tutorial: How to use<br /> Chart PaletteCustomColors in asp.net</h2>
<hr width="450" align="left" color="CornFlowerBlue" />
<br />
<asp:Chart
ID="Chart1"
runat="server"
Palette="SeaGreen"
>
<Legends>
<asp:Legend
Name="ChartLegend"
Docking="Top"
Alignment="Center"
>
</asp:Legend>
</Legends>
<Series>
<asp:Series
Name="Salary"
YValueType="Int32"
ChartType="Pie"
ChartArea="DefaultChartArea"
>
<Points>
<asp:DataPoint AxisLabel="Jenny" YValues="7400" />
<asp:DataPoint AxisLabel="Sonali" YValues="28695" />
<asp:DataPoint AxisLabel="Masuma" YValues="11250" />
<asp:DataPoint AxisLabel="Popy" YValues="9750" />
<asp:DataPoint AxisLabel="Jones" YValues="31500" />
</Points>
</asp:Series>
</Series>
<ChartAreas>
<asp:ChartArea
Name="DefaultChartArea"
Area3DStyle-Enable3D="true"
>
</asp:ChartArea>
</ChartAreas>
</asp:Chart>
<br />
<asp:Button
ID="Button1"
runat="server"
Text="Set Chart Custom Palette"
Font-Bold="true"
OnClick="Button1_Click"
ForeColor="DarkBlue"
Height="45"
/>
</div>
</form>
</body>
</html>
