Chart ChartType Spline
ChartTypeSpline.aspx
<%@ Page Language="C#" AutoEventWireup="true" %>
<!DOCTYPE html>
<script runat="server">
protected void Button1_Click(object sender, System.EventArgs e)
{
Chart1.Series["ExamResult"].ChartType = SeriesChartType.Spline;
Label1.Text = "ChartType now Spline";
Label1.BackColor = System.Drawing.Color.Crimson;
}
</script>
<html xmlns="http://www.w3.org/1999/xhtml">
<head id="Head1" runat="server">
<title>How to set change Chart ChartType Spline programmatically in asp.net</title>
<style type="text/css">
h2
{
color:DarkBlue;
font-style:italic;
}
</style>
</head>
<body>
<form id="form1" runat="server">
<div>
<h2>Chart example and tutorial: How to set change<br />Chart ChartType Spline programmatically in asp.net</h2>
<hr width="500" align="left" color="CornflowerBlue" />
<br />
<asp:Label
ID="Label1"
runat="server"
Font-Size="Large"
Font-Names="Comic Sans MS"
Width="525"
ForeColor="White"
>
</asp:Label>
<br />
<asp:Chart
ID="Chart1"
runat="server"
BorderlineDashStyle="Solid"
BorderlineWidth="2"
BorderlineColor="Wheat"
Width="525"
BackColor="Olive"
>
<Series>
<asp:Series
Name="ExamResult"
YValueType="Int32"
ChartArea="ChartArea1"
Color="OliveDrab"
>
<Points>
<asp:DataPoint AxisLabel="Mouli" YValues="96" />
<asp:DataPoint AxisLabel="Laltu" YValues="38" />
<asp:DataPoint AxisLabel="Boruna" YValues="77" />
<asp:DataPoint AxisLabel="Koni" YValues="74" />
<asp:DataPoint AxisLabel="Sana" YValues="26" />
</Points>
</asp:Series>
</Series>
<ChartAreas>
<asp:ChartArea
Name="ChartArea1"
BackColor="Snow"
BorderDashStyle="Solid"
BorderColor="PaleTurquoise"
BorderWidth="2"
>
<Area3DStyle Enable3D="true" LightStyle="Simplistic" />
<AxisX LineColor="Olive"></AxisX>
<AxisY LineColor="Olive"></AxisY>
</asp:ChartArea>
</ChartAreas>
</asp:Chart>
<br />
<asp:Button
ID="Button1"
runat="server"
Text="Set Chart ChartType Spline"
Font-Bold="true"
OnClick="Button1_Click"
Font-Names="Comic Sans MS"
ForeColor="Crimson"
Height="45"
/>
</div>
</form>
</body>
</html>
