Creating a master/Detail page using GridView
MasterDetailsPageExample.aspx
<%@ Page Language="C#" %>
<!DOCTYPE html>
<script runat="server">
</script>
<html xmlns="http://www.w3.org/1999/xhtml">
<head runat="server">
<title>asp.net GridView example: a sample simple Master-Details page</title>
</head>
<body>
<form id="form1" runat="server">
<div>
<asp:Label ID="Label1" runat="server" ForeColor="LightSlateGray" Font-Bold="true" Font-Size="X-Large">
Master-Details Page Example
</asp:Label>
<br /><br />
<asp:SqlDataSource
ID="SqlDataSource1"
runat="server"
ConnectionString="<%$ ConnectionStrings:NorthwindConnectionString %>"
SelectCommand="SELECT CategoryID, CategoryName, Description FROM Categories"
>
</asp:SqlDataSource>
<asp:GridView
ID="GridView1"
runat="server"
DataSourceID="SqlDataSource1"
AutoGenerateSelectButton="true"
DataKeyNames="CategoryID"
BackColor="HotPink"
ForeColor="Snow"
BorderColor="LightPink"
HeaderStyle-BackColor="DarkOrange"
>
<SelectedRowStyle ForeColor="HotPink" BackColor="Snow" />
</asp:GridView>
<asp:SqlDataSource
ID="SqlDataSource2"
runat="server"
ConnectionString="<%$ ConnectionStrings:NorthwindConnectionString %>"
SelectCommand="SELECT ProductID, ProductName, UnitPrice FROM Products WHERE CategoryID=@CategoryID"
>
<SelectParameters>
<asp:ControlParameter Name="CategoryID" ControlID="GridView1" PropertyName="SelectedDataKey.Value" />
</SelectParameters>
</asp:SqlDataSource>
<br />
<asp:Label
ID="Label2"
runat="server"
Text="Products in selected Category"
Font-Size="Large"
ForeColor="LightSlateGray"
>
</asp:Label>
<br />
<asp:GridView
ID="GridView2"
runat="server"
DataSourceID="SqlDataSource2"
AllowSorting="false"
AllowPaging="true"
PageSize="5"
BackColor="SteelBlue"
ForeColor="WhiteSmoke"
>
</asp:GridView>
</div>
</form>
</body>
</html>
